Description

The GT3582 Represents The Pinnacle Of Legacy Garrett GT Series Engineering,
Renowned For Delivering Balanced Powerband Suitable For Both High-Performance
Street Cars And Dedicated Competition Vehicles. This Turbocharger Is Designed
As A Complete, Direct-Replacement Assembly For Applications Utilizing The T3 Flanged Footprint.

At Its Core, The GT3582 Utilizes A Robust Journal Bearing System, Offering Exceptional Durability
And Reliability For High-Horsepower Applications Where Consistent Oil Pressure Is Maintained.
The 61.4mm Inducer Compressor Wheel Is Housed Within A 0.70 A/R Compressor Cover, Optimized For High-Flow Efficiency And Reduced Turbo Lag. On The Hot Side, The Turbine Housing Features A T3 Divided Inlet Flange With A 0.82 A/R Specification, Striking An Optimal Balance Between Rapid Spool Characteristics And Top-End Volumetric Flow

Included Gaskets

To Facilitate A Secure And Leak-Free Installation, This Unit Is Supplied Exclusively With The Necessary Sealing Components. Please Verify Flange Configurations prior To Installation

1 x T3 Divided Inlet Gasket: Composite Multi-layer Gasket Designed To Seal The Interface Between The Exhaust Manifold And The Turbocharger’s Turbine Inlet Flange

1 x 5-Bolt Turbine Outlet (Discharge) Gasket: High-Temperature Graphite Composite Gasket Engineered To Seal The Connection Between The Turbine Housing Outlet And The Downpipe.

Specifications Summary

Center Housing: Oil-Cooled Only (Journal Bearing)

Compressor Specs: 61.4mm Inducer / 82mm Exducer

Compressor Housing: 4.0″ Inlet / 2.5″ Outlet (0.70 A/R)

Turbine Specs: 68mm Inducer / 62mm Exducer

Turbine Housing: T3 Divided Inlet (0.82A/R) – 5-Bolt Outlet

Important Notes

No Additional Accessories: This Listing Included The Turbocharger Assembly And The Specified Gaskets Only. Oil Feed Lines, Oil Drain Flanges, Coolant Lines, Fasteners, Banjo Bolts, Studs, And Wastegate, Actuators Are Not Included.

No Fitment Instructions: Installation Procedures, Torque Specifications, And Vehicle-Specific Fitment Validation Are Not provided. Professional Fabrication And Tuning Are Recommended To Ensure Optimal performance And Component Longevity
